CM250BV Variable Frequency Oil-free Screw Air Compressor Of Water Lubrication

Advantages of Our oil-free air compressor

1. Truly Oil-free Screw Air Compressor

Unlike traditional air compressors, our CM250BV Variable Frequency Oil-free Screw Air Compressor does not use a single drop of lubrication oil. The compressor hosts are kept clean by washing away any acidic or alkaline substances in the compressed air with pure water, ensuring the air remains pure and uncontaminated.

2. Lifelong Reliable Oil-free Screw Air Compressor

Our compressor is not only oil-free, but also incredibly durable. All pipelines are made from corrosion-resistant materials like 304 and 316 stainless steel. The compressor uses direct drive technology, keeping the maximum rotation speed under 2980rpm/min, ensuring long-lasting use of bearings and rotors.

3. More Energy-efficient Oil-free Screw Air Compressor

Our compressor uses direct water spraying to cool the rotor and cavity, resulting in higher isothermal compression efficiency. It employs dual compression chamber technology, which surpasses two-stage compression and eliminates the need for intermediate cooling, thus reducing power consumption.

4. Lower Maintenance Cost Oil-free Screw Air Compressor

Our compressor is also cost-effective when it comes to maintenance. Regular upkeep only requires the replacement of air and water filters.

Compression Principle of Our Oil-free Screw Air Compressor

In our oil-free screw air compressor, the compression process is carried out by a pair of main screws, the pressure screw and the rotating screw, which are typically made of high-strength alloy steel and have precise spiral shapes. During the intake process, the spiral shape of the screws forms a sealed working chamber. As the screws rotate, this chamber gradually expands, drawing external air into the chamber through the intake port. Once the air is inside, the chamber gradually reduces its size due to the rotation of the screws, slowly increasing the compression ratio and thus the pressure of the air. This compressed air is then pushed towards the machine's exit. The compression process generates heat, so a cooling system is necessary to maintain a manageable temperature. Moreover, the compressed air needs to pass through a filtration system to remove any potential contaminants and particles.

Applications of Oil-free Screw Air Compressor

1. Food and Beverage Industry: Our oil-free air compressor provides an oil-free air supply, eliminating the risk of oil contamination. It's perfect for pneumatic operations, packaging, and processing in the food and beverage industry.

2. Medical Industry: With the ability to deliver sterile, oil-free air, our compressor is ideal for surgical rooms, laboratories, and other medical equipment.

3. Pharmaceutical Industry: Our compressor provides oil-free, sterile air that meets pharmaceutical standards, making it suitable for pneumatic transportation, packaging, and sterilization in pharmaceutical production.

4. Electronics Industry: Our compressor supplies clean air, preventing oil contamination that could damage electronic components. It's well-suited for pneumatic tools, electronic component blowouts, and cleaning applications.

About Our Company

Our company's full range of products has passed German TUV class 0 oil-free certification, CE certification, ISO9001 certification, and TS16949 certification. We are the first domestic enterprise to use water for internal cooling and lubrication of high-end screw compressors and have pioneered the launch of a two-stage compression high-pressure micro oil screw compressor with a pressure of up to 4.0MPa. We have also developed the world's first 4.0MPa pressure oil-free screw compressor and the world's first 1.25MPa pressure oil-free scroll compressor.
