MRV050 Worm Gear Reducer for Intelligent Home

MRV050 Worm Gear Reducer for Intelligent Home
Category: Tags: , , ,
Get a Quote

The MRV050 Worm Gear Reducer is an exceptional equipment, specifically designed for automatic car washers and intelligent homes. This modified RV reducer offers higher cost performance, wider applicability, and retains the advantages of the XRV series. It provides a more convenient and flexible installation process compared to the XRV series. With a supporting motor power ranging from 0.25kw to 0.75kw and matching flanges, it meets diverse customer needs.

Technical Parameters of MRV050 Worm Reducer

Type Ratio Flange Power
MRV050 5     7.5  10     12  15     20  30     40  50     60  80    100 71B14 0.06KW 0.09KW 0.12KW 0.18KW 0.20KW 0.25KW 0.37KW 0.55KW 0.75KW 1.1KW 1.5KW 2.2KW 3KW 4KW 5.5KW 7.5KW
80B14
Type i n2/r/min Mn2/Nm Fr2/N Motor P1/kw L/mm
MRV050 5 280 17 1577 7134 0.55 180
280 23 1577 8024 0.75 205
7.5 187 25 1805 7134 0.55 180
187 34 1805 8024 0.75 205
10 140 22 1987 7124 0.37 180
140 32 1987 7134 0.55 180
140 44 1987 8024 0.75 205
12 117 26 2016 7124 0.37 180
117 33 2016 7134 0.55 205
117 48 2016 8024 0.75 205
15 93 31 2274 7124 0.37 180
93 46 2274 7134 0.55 180
93 63 2274 8024 0.75 205
20 70 27 2503 7114 0.25 180
70 40 2503 7124 0.37 180
70 59 2503 7134 0.55 180
70 81 2503 8024 0.75 205
25 56 32 2696 7114 0.25 180
56 48 2696 7124 0.37 180
56 71 2696 7134 0.55 180
30 47 37 2865 7114 0.25 180
47 55 2865 7124 0.37 180
47 81 2865 7134 0.55 180
40 35 33 3153 7114 0.25 180
35 46 3153 7124 0.37 180
35 68 3153 7134 0.55 180
50 28 54 3397 7114 0.25 180
28 72 3397 7124 0.37 180
28 80 3397 7134 0.55 180
52 27 55 3482 7114 0.25 180
27 73 3482 7124 0.37 180
27 82 3482 7134 0.55 180
60 23 60 3610 7114 0.25 180
23 75 3610 7124 0.37 180
23 84 3610 7134 0.55 180
80 18 64 3973 7114 0.25 180
18 77 3973 7124 0.37 180
18 89 3973 7134 0.55 180
100 14 68 4280 7114 0.25 180
14 79 4280 7124 0.37 180
14 93 4280 7134 0.55 180

Key Features of MRV050 Worm Reducer

  • Modular flange and other component options, allowing for universal mounting configurations.
  • Large ratio range suitable for various applications.
  • A compact body that fits most equipment structures.
  • IP Grade that can reach IP67, adaptable to most spraying conditions.
  • Full-Synthetic Oil lubrication for optimal performance.
  • The housing material is ADC12 with powder painting, offering better anticorrosive properties and appearance.
  • Sealing with NOK oil seal (NBR) for excellent sealability.
  • Worms material is 20CrMnTi with carburizing and quenching, ensuring high wear resistance.

Applications of the MRV050 Worm Reducer

The MRV050 Worm Reducer is versatile and can be applied in various industries and equipment including:

  • Packaging Equipment
  • Food Machinery
  • Conveying Equipment
  • Warehousing and Logistics
  • Electric Doors and Windows
  • Intelligent Drive Systems
  • Pharmaceutical Equipment
  • Precision Equipment
  • Intelligent Home Systems
  • Dyeing & Textile Equipment
  • Medical Equipment
  • Car Wash Machines, and much more.

Worm gear reducer applications

Choosing the Right Worm Gear Reducer

When selecting a worm gear reducer, consider the following:

  • Application requirements: Consider the nature of your application, material, and environmental conditions.
  • Load capacity: Ensure the gear reducer can handle the required load capacity.
  • Size and installation: Choose a model that fits your equipment structure and allows for easy installation.
  • Cost and efficiency: Look for a model that offers high cost performance and efficiency.

Motors for Worm Gear Reducers

Choosing the right motor to pair with your worm gear reducer is crucial for optimal performance. It is necessary to match the motor's power with the reducer's load requirements. We also provide suitable electric motors for your convenience.

Motor Dimensions

IP67 Motor Dimension

IP67 Motor Dimension

IP67 Motor Dimension

IP56 Motor Dimension

Type IP56 Motor IP67 Motor
RV/De L D ΦC ΦS T L D ΦC ΦS T
71B14 190 140 85 14 M6 180 120 85 14 M6
80B14 215 158 100 19 M6 205 135 100 19 M6

<a href=

Trust HZPT for Quality Worm Gear Reducers

HZPT is a comprehensive transmission equipment manufacturer with over 15 years of experience. We are trusted by customers in Europe, America, Africa, Asia, and other regions. Our commitment to quality, service, and competitive pricing makes us an ideal partner for your worm gear reducer needs.

Worm gearbox factory

Frequently Asked Questions

Q1: What is the power range of MRV050 Worm Reducer?

A1: The MRV050 Worm Reducer supports a motor power range from 0.25kw to 0.75kw.

Q2: How does the MRV050 Worm Reducer compare to the XRV series?

A2: The MRV050 Worm Reducer offers a more convenient and flexible installation process compared to the XRV series, but retains many of its advantages.

Q3: Can the MRV050 Worm Reducer be used in a car wash machine?

A3: Yes, the MRV050 Worm Reducer is designed to be used in a car wash machine, offering high cost performance and wide applicability.
