Timing Belt Pulley L Type

Timing belt pulleys connect and synchronize the rotation between two shaft systems. Automobiles, for example, use a timing belt pulley component to link the cam and crankshafts. The gear body of the pulley is lined with teeth that ensure the shafts do not slip. By directly coordinating the rotary motion of each shaft, the engine valves can open and close in proper timing and sequence.

Category:
Get a Quote

Timing belt pulleys connect and synchronize the rotation between two shaft systems. Automobiles, for example, use a timing belt pulley component to link the cam and crankshafts. The gear body of the pulley is lined with teeth that ensure the shafts do not slip. By directly coordinating the rotary motion of each shaft, the engine valves can open and close in proper timing and sequence.

Products Description

Product  Name  Timing Belt Pulley
Teeth profile  Trapezoidal toothed  MXL, XXL, XL, L, H, XH, XXH
 T-toothed  T2.5, T5, T10, T20
 Arc toothed  HTD3M, HTD5M, HTD8M, HTD14M, HTD20M, Gt2,  Gt3, Gt5
 S-toothed  S2M, S3M, S4.5M, S5M, S8M, S14M
 Parabolic-toothed  P2M, P3M, P5M, P8M, P14M
 Y-toothed  G2M, G3M, G5M, Y8M
 Teeth Quantity  10-150 teeth or customized
 Inner Bore  2-200mm H7 precision or customized
 Belt width  4mm, 6mm, 9mm, 10mm, 12mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm, 1/4'', 5/16'', 3/8'', 1/2'', 3/4'', 1'', 1.5'', 2''or customized
 Accessories  We can provide the service of assembling setscrews, bearings, shafts, or taper bush.
 Surface  treatment  Anodize, Black Oxide, Phosphate, and Galvanization
 Drawing Format  Timing belt pulley cad drawing, timing belt pulley UG drawing, Timing belt Pulley Soilwork drawing, Timing Pulley PDF drawing

Advantages of Timing Belt Pulley

Timing belt pulleys are available with lots of advanced features. Hence these pulleys are widely used in various industrial sectors such as textile, paper making, printing machinery, agriculture, and more. So, the advantages that are mainly available from these pulleys are mentioned below.

  • These are available with high torque carrying capacity
  • These are robust construction, so there will be no slipping between the belt and the pulley.
  • These help in transmitting the power at a constant speed.
  • Timing belt pulleys are available at a high strength
  • These are resistant to corrosion and available with features for low noise and vibration
  • Another essential advantage of this pulley is that it possesses a long life.
  • These pulleys are available in the market in varied sizes and models.

Why Choose Us Timing Belt Pulley?

Timing pulleys are widely used in various equipment where the timing of both drives is precious, and the display ratio is essential. A timing pulley's benefit is eliminating slippage and maintaining constant angular velocity. Timing pulleys are manufactured per international and national standards with carbon steel/alloy steel/aluminum and hardened teeth to provide long life. We have been ranked as the most dependable and leading firm worldwide and actively emerged to offer a wide array of timing belts. Our sophisticated production unit's timing pulleys are fabricated by our skilled personnel using advanced technology.

Known for superior sturdiness, dimensional accuracy, and durability, the offered range is manufactured in compliance with industry norms and guidelines. Further, we provide these components in various customized forms according to patrons' specific requirements. Apart from this, these pulleys are quality tested by our quality controllers on different parameters.

1) Warranty: our timing pulley's quality is excellent, and with insurance within one year, when you receive the products and find quality problems, we promise you could return it and free maintenance.
2) Drawings: please send your timing pulleys' drawings to us to get the best quotation; If you have no drawings, please get in touch with us, then we can work out CAD drawings and the best reference for you ASAP.
3) Sample: we accept one-piece sample orders. We could do examples until you're satisfied.
4) Confidentiality agreement: Strictly adherence to client confidentiality agreement for timing pulleys.
