Two Piece Heavy Duty Shaft Collars (Shaft Clamps) Inch Series

The inch series two piece heavy duty shaft collars are a type of shaft collar that is made of steel and has a black oxide finish. They are designed for heavy-duty applications that require large shafts, such as steel manufacturing. The two-piece design allows them to be installed or repositioned anywhere on the shaft without disturbing existing components. They accommodate a greater variety of shaft diameters than setscrew collars and are effective on both hard and soft shafts. The inch series two piece heavy duty shaft collars are available in a variety of sizes, with bore sizes ranging from 3″ to 6″. They are also available in a variety of materials, including steel, stainless steel, and aluminum.

Get a Quote

Two Piece Heavy Duty Shaft Collars (Shaft Clamps) Inch Series

The inch series two piece heavy duty shaft collars are a type of shaft collar that is made of steel and has a black oxide finish. They are designed for heavy-duty applications that require large shafts, such as steel manufacturing. The two-piece design allows them to be installed or repositioned anywhere on the shaft without disturbing existing components. They accommodate a greater variety of shaft diameters than setscrew collars and are effective on both hard and soft shafts.

The inch series two piece heavy duty shaft collars are available in a variety of sizes, with bore sizes ranging from 3" to 6". They are also available in a variety of materials, including steel, stainless steel, and aluminum. Inch series two piece heavy duty shaft collars are commonly used in industries such as manufacturing, automotive, and aerospace, as well as in various types of machinery and equipment. If you are looking for a heavy-duty shaft collar that can handle the demands of your application, then an inch series two piece heavy duty shaft collar is a great option.

Two Piece Heavy Duty Shaft Collars (Shaft Clamps) Inch Series Two Piece Heavy Duty Shaft Collars (Shaft Clamps) Inch Series

▍Two Piece Heavy Duty Shaft Collar Sizes Chart (Inch Series)

Two Piece Heavy Duty Shaft Collar Sizes Chart (Inch Series) Two Piece Heavy Duty Shaft Collar Sizes Chart (Inch Series)
Part Number Steel Part Number Stainless Steel Bore (B) (in) Outer Diameter (OD) (in) Width (W) (in)
SPH-48-F SPH-48-SS 3.0000 in 5 in 1.375 in
SPH-49-F SPH-49-SS 3.0625 in 5 in 1.375 in
SPH-50-F SPH-50-SS 3.1250 in 5 in 1.375 in
SPH-51-F SPH-51-SS 3.1875 in 5 in 1.375 in
SPH-52-F SPH-52-SS 3.2500 in 5 in 1.375 in
SPH-53-F SPH-53-SS 3.3125 in 5 1/4 in 1.375 in
SPH-54-F SPH-54-SS 3.3750 in 5 1/4 in 1.375 in
SPH-55-F SPH-55-SS 3.4375 in 5 1/4 in 1.375 in
SPH-56-F SPH-56-SS 3.5000 in 5 1/4 in 1.375 in
SPH-57-F SPH-57-SS 3.5625 in 5 1/2 in 1.375 in
SPH-58-F SPH-58-SS 3.6250 in 5 1/2 in 1.375 in
SPH-59-F SPH-59-SS 3.6875 in 5 1/2 in 1.375 in
SPH-60-F SPH-60-SS 3.7500 in 5 1/2 in 1.375 in
SPH-61-F SPH-61-SS 3.8125 in 5 3/4 in 1.375 in
SPH-62-F SPH-62-SS 3.8750 in 5 3/4 in 1.375 in
SPH-63-F SPH-63-SS 3.9375 in 5 3/4 in 1.375 in
SPH-64-F SPH-64-SS 4.0000 in 5 3/4 in 1.375 in
SPH-65-F SPH-65-SS 4.0625 in 6 in 1.375 in
SPH-66-F SPH-66-SS 4.1250 in 6 in 1.375 in
SPH-67-F SPH-67-SS 4.1875 in 6 in 1.375 in
SPH-68-F SPH-68-SS 4.2500 in 6 in 1.375 in
SPH-69-F SPH-69-SS 4.3125 in 6 1/4 in 1.375 in
SPH-70-F SPH-70-SS 4.3750 in 6 1/4 in 1.375 in
SPH-71-F SPH-71-SS 4.4375 in 6 1/4 in 1.375 in
SPH-72-F SPH-72-SS 4.5000 in 6 1/4 in 1.375 in
SPH-73-F SPH-73-SS 4.5625 in 6 1/2 in 1.375 in
SPH-74-F SPH-74-SS 4.6250 in 6 1/2 in 1.375 in
SPH-75-F SPH-75-SS 4.6875 in 6 1/2 in 1.375 in
SPH-76-F SPH-76-SS 4.7500 in 6 1/2 in 1.375 in
SPH-77-F SPH-77-SS 4.8125 in 6 3/4 in 1.375 in
SPH-78-F SPH-78-SS 4.8750 in 6 3/4 in 1.375 in
SPH-79-F SPH-79-SS 4.9375 in 6 3/4 in 1.375 in
SPH-80-F SPH-80-SS 5.0000 in 6 3/4 in 1.375 in
SPH-81-F SPH-81-SS 5.0625 in 7 in 1.375 in
SPH-82-F SPH-82-SS 5.1250 in 7 in 1.375 in
SPH-83-F SPH-83-SS 5.1875 in 7 in 1.375 in
SPH-84-F SPH-84-SS 5.2500 in 7 in 1.375 in
SPH-85-F SPH-85-SS 5.3125 in 7 1/4 in 1.375 in
SPH-86-F SPH-86-SS 5.3750 in 7 1/4 in 1.375 in
SPH-87-F SPH-87-SS 5.4375 in 7 1/4 in 1.375 in
SPH-88-F SPH-88-SS 5.5000 in 7 1/4 in 1.375 in
SPH-89-F SPH-89-SS 5.5625 in 7 1/2 in 1.375 in
SPH-90-F SPH-90-SS 5.6250 in 7 1/2 in 1.375 in
SPH-91-F SPH-91-SS 5.6875 in 7 1/2 in 1.375 in
SPH-92-F SPH-92-SS 5.7500 in 7 1/2 in 1.375 in
SPH-93-F SPH-93-SS 5.8125 in 7 3/4 in 1.375 in
SPH-94-F SPH-94-SS 5.8750 in 7 3/4 in 1.375 in
SPH-95-F SPH-95-SS 5.9375 in 7 3/4 in 1.375 in
SPH-96-F SPH-96-SS 6.0000 in 7 3/4 in 1.375 in

▍Features of Two Piece Heavy Duty Shaft Collars

Two-piece heavy duty shaft collars are designed to provide a high clamping force to securely hold components in place on a shaft. Some of the key features of these heavy duty shaft collars include:

1. Two-piece design: The two-piece design of these heavy duty shaft collars allows for easy installation and removal without the need to slide them onto the end of the shaft. This can save time and effort when making adjustments or repairs to machinery.

2. High clamping force: Two-piece heavy duty shaft collars typically have a higher clamping force than standard collars, which helps to prevent slippage and movement of components on the shaft.

3. Multiple screws: These two-piece heavy duty shaft collars often have multiple screws to evenly distribute the clamping force around the circumference of the collar. This can help to reduce the likelihood of distortion or damage to the shaft.

4. Durable materials: Two-piece heavy duty shaft collars are typically made from high-strength materials such as stainless steel or aluminum, which provide excellent resistance to corrosion and wear.

5. Wide range of sizes: These two-piece heavy duty shaft collars are available in a wide range of sizes to fit various shaft diameters and thicknesses, making them a versatile solution for many different types of machinery.

6. Versatile applications: These two-piece heavy duty shaft collars are commonly used in industries such as manufacturing, automotive, and aerospace, as well as in various types of machinery and equipment.

▍Two Piece Heavy Duty Shaft Collars Common Applications

Two-piece heavy duty shaft collars are used in a wide range of applications where a secure and precise shaft connection is required. The two-piece design allows for easy installation and removal without having to remove other components from the shaft. Here are some common applications for two-piece heavy duty shaft collars:

(1) Industrial Machinery: Two-piece heavy duty shaft collars are commonly used in industrial machinery, such as conveyors, pumps, and power transmission equipment. They are used to secure the shaft to the machine and prevent slippage or misalignment.

(2) Robotics and Automation: Two-piece heavy duty shaft collars are also used in robotics and automation applications, where precise shaft positioning and alignment are critical. They are often used in the construction of robotic arms and other automated systems.

(3) Aerospace and Defense: Two-piece heavy duty shaft collars are used in aerospace and defense applications, where reliability and precision are essential. They are used in critical components such as guidance systems, navigation systems, and aircraft engines.

(4) Medical Equipment: Two-piece heavy duty shaft collars are used in medical equipment, such as imaging equipment and surgical tools. They are used to secure shafts and prevent misalignment during operation.

(5) Agricultural Equipment: Two-piece heavy duty shaft collars are commonly used in agricultural equipment, such as tractors and harvesting machines. They are used to secure shafts and prevent slippage or misalignment during operation.

Overall, two-piece heavy duty shaft collars are used in a wider range of applications where a secure and precise shaft connection is required. They are particularly useful in applications where the shaft needs to be easily removed or adjusted without having to remove other components from the shaft.

Two Piece Heavy Duty Shaft Collars Common Applications Two Piece Heavy Duty Shaft Collars Common Applications

▍How to Choose the Right Two Piece Heavy Duty Shaft Collars?

Choosing the right two-piece heavy duty shaft collars requires consideration of several factors, such as the application requirements, material selection, and shaft collar design. Here are some things to consider:

Shaft Size: The first and most crucial factor to consider is the shaft size. The heavy duty shaft collars should fit snugly on the shaft without being too tight or too loose, which can cause slippage or damage to the shaft.

Material Selection: The material of the heavy duty shaft collars should be chosen based on the application requirements. Two-piece heavy-duty shaft collars are commonly made from steel, stainless steel, aluminum, or plastic. Steel and stainless steel are suitable for high-stress applications, while aluminum is lightweight and corrosion-resistant.

Shaft Collar Design: The design of the heavy duty shaft collars should be chosen based on the application requirements. Two piece shaft collars are designed to be easily installed and removed from the shaft without having to remove other components from the assembly. Some shaft collars have set screws while others use clamping mechanisms to secure the shaft collar to the shaft.

Load Capacity: The heavy duty shaft collar's load capacity should be considered to ensure that it can handle the application's load requirements. The heavy duty shaft collar's load capacity is determined by its material, size, and design.

Environment: The environment in which the heavy duty shaft collars will be used should be considered. For example, if the shaft collar will be used in a high-temperature environment, a material with high-temperature resistance, such as stainless steel, would be appropriate. Similarly, if the heavy duty shaft collar will be used in a corrosive environment, a material with corrosion resistance, such as aluminum or plastic, should be chosen.

Special Features: Some two-piece heavy duty shaft collars have special features that can enhance their performance, such as split shaft collars, which allow for easy installation and removal without disturbing other components in the assembly. Other features include threaded holes for mounting accessories, keyways for locking the collar onto the shaft, and precision bores for accurate alignment.

▍We Also Provide Other Types of Shaft Collars

Other Types of Shaft Collars

▍Two Piece Heavy Duty Shaft Collar Manufacturers

Shaft collars are machine components that feature a simple design but play an important role in a wide range of industrial applications. They serve three primary functions; holding components in place, locating or positioning components on a shaft, and creating an attachment between the shaft and another component. Designers have a variety of factors to consider, such as style, material, bore size, and shaft geometry, before a selection can be made. It is important to identify the requirements, parameters, and limitations of your system in order to determine the right style for the application.

Despite their simple design, shaft collars play an important role in a wide range of industrial applications. As such, when choosing one for a particular application, it is essential to use the one with the right design and performance characteristics.

As an experienced manufacturer and distributor of shaft collars suitable for use in power transmission, motion control, automation, and other OEM and MRO operations, HZPT has the knowledge, skills, and inventory to help customers select and source the right shaft collar for their application. In addition to offering standard shaft collars, including set screw shaft collars, one piece shaft collars, two piece shaft collars, quick release shaft collars, double wide shaft collars, heavy duty shaft collars, mountable shaft collars, hex shaft collars, D profile shaft collars, and threaded shaft collars, we also provide custom design and engineering services to manufacturing specialized shaft collars for unique customer needs.

Heavy Duty Shaft Collar Manufacturers

▍FAQ

Q: What materials are heavy duty shaft collars made of?
A: Heavy duty shaft collars are typically made from durable materials such as stainless steel, aluminum, or brass. The selection of material depends on the specific application requirements, such as load capacity, strength, and corrosion resistance.

Q2: How are heavy duty shaft collars installed?
A: Heavy duty shaft collars are installed by placing them around the shaft and tightening the screws or bolts to secure them in place. They can be easily adjusted and repositioned as needed.

Q3: What is the difference between a heavy duty shaft collar and a regular shaft collar?
A: The primary difference between a heavy duty shaft collar and a regular shaft collar is the load capacity. Heavy-duty shaft collars are designed to handle higher loads and torque than regular shaft collars, making them suitable for use in heavy-duty applications.

Q4: Can heavy duty shaft collars be used in high-temperature environments?
A: Yes, heavy duty shaft collars can be made from materials that can withstand high temperatures, such as stainless steel or titanium. However, the specific material selection depends on the temperature range and other environmental factors.

Q5: Can heavy duty shaft collars be used in corrosive environments?
A: Yes, heavy duty shaft collars can be made from materials that are resistant to corrosion, such as stainless steel or brass. The selection of material depends on the specific corrosive environment and the level of corrosion resistance required.

Q6: Can heavy duty shaft collars be used for misaligned shafts?
A: Heavy duty shaft collars can accommodate some degree of shaft misalignment, but it is generally recommended to use flexible couplings or other specialized components for significant misalignment.

Q7: Are heavy duty shaft collars adjustable?
A: Yes, heavy duty shaft collars are adjustable and can be easily repositioned or removed as needed. They are typically split in two halves with screws or bolts to allow for easy installation and adjustment.

Q8: What is the maximum load capacity of a heavy duty shaft collar?
A: The maximum load capacity of a heavy duty shaft collar depends on the specific design, material, and size. It is essential to select the appropriate collar based on the application requirements to ensure safe and reliable operation.

Q9: Can heavy duty shaft collars be used in high-speed applications?
Yes, heavy duty shaft collars can be used in high-speed applications, but it is essential to select the appropriate collar with features such as balanced design and precise machining to prevent vibration and other issues.

Q10: Can heavy duty shaft collars be used for shafts of different sizes?
A: Yes, heavy duty shaft collars are available in various sizes and configurations to accommodate different shaft sizes and types. It is essential to select the appropriate collar based on the shaft diameter and other application requirements.
