X678 Drop Forged Rivetless Chain Sprockets

 X678A Sprocket

This drop forged rivetless A-plate sprocket is manufactured specifically for X678 chain, and is designed to work with the chain and attachments as smoothly as possible. However, some applications require sprockets that have an extra clearance that is commonly known as the "relief area". We offer both styles as shown below, make sure to let us know what your application is or which style of sprocket you need so we can get you the exact match for your application. We offer some of the best pricing in the industry while supplying you with a high quality and durable sprocket.

  • High Quality Sprocket
  • Manufactured For X-678 Chain
  • Two Styles To Choose From
  • Extremely Durable
  • Optimum Performance

Sprocket Number Tooth Count Pitch Style Stock Bore Weight (LBS)
X-678A5 5 6.031" A-Plate 1.500" 85.00 LBS
X-678A6 6 6.031" A-Plate 1.500" 121.00 LBS
X-678A7 7 6.031" A-Plate 1.500" 137.00 LBS
X-678A8 8 6.031" A-Plate 1.500" 173.00 LBS
X-678A9 9 6.031" A-Plate 1.500" 194.00 LBS
X-678A10 10 6.031" A-Plate 1.500" 236.00 LBS
X-678A11 11 6.031" A-Plate 1.500" 283.00 LBS
X-678A12 12 6.031" A-Plate 1.500" 316.00 LBS



X678C Sprocket

This drop forged rivetless C-hub sprocket is manufactured specifically for X678 chain, and is designed to work with the chain and attachments as smoothly as possible. However, some applications require sprockets that have an extra clearance that is commonly known as the "relief area". We offer both styles as shown below, make sure to let us know what your application is or which style of sprocket you need so we can get you the exact match for your application. We offer some of the best pricing in the industry while supplying you with a high quality and durable sprocket.

  • High Quality Sprocket
  • Manufactured For X-678 Chain
  • C-Hub Style (Hub On Both Sides)
  • Two Styles To Choose From
  • Extremely Durable
  • Optimum Performance

Sprocket Number Tooth Count Pitch Diameter Style Hub Diameter Length Thru Bore Maximum Bore Weight (LBS)
X-678C5 5 19.517" C-Hub 7.000" 6.000" 4.440" 137.00 LBS
X-678C6 6 23.302" C-Hub 7.000" 6.000" 4.440" 173.00 LBS
X-678C7 7 27.103" C-Hub 7.000" 6.000" 4.440" 188.00 LBS
X-678C8 8 30.914" C-Hub 8.000" 6.250" 5.440" 243.00 LBS
X-678C9 9 34.731" C-Hub 8.000" 6.250" 5.440" 264.00 LBS
X-678C10 10 38.553" C-Hub 8.000" 6.250" 5.440" 306.00 LBS
X-678C11 11 42.378" C-Hub 8.000" 6.250" 5.440" 379.00 LBS
X-678C12 12 46.205" C-Hub 8.000" 6.250" 5.440" 412.00 LBS



We aslo offer a full range of both precision roller chain and engineered.

Applications are varied and range from conveyor, elevator transfer to broad general industrial power transmission specialty applications with attachments and/or special materials are also available.

industries we service

We promise will offer the best price by the high quality in china! We also accept special order about the products. If you are interested in our products. Please do not hesitate to let us know.We are pleased to give you the detailed information.We promise that our products would be safety and were in high quality and reasonable price. If you are interested in our products, please contact us asap.We are sincerely looking for your cooperation.

Most of our products are exported to Europe or Americas, both standard and nonstandard products available. We can produce as per your drawing or sample. Material can be standard or as per your special request. If you choose us, you choose reliable.
